| Heavy Duty Safety Stitch Machines Styles 81300
|
 |
| Styles / Tabling | Description |
| 81300A Needles: 2 Needle distance: 5.0 mm Threads: 4 Stitch range: 6.3-13 mm Standard: 10 mm |
Safety stitch machine with top and bottom feed for matched seams on heavy container bags. 5 mm distance from needle to needle. Overedge seam width 10 mm = total 15 mm. Sewing capacity up to 19 mm. Max. speed 1400 RPM, stitch type (401.502). |
| UN280G132 alternatively: UN280A852L alternatively: UN280A735L |
Non-submerged; Motor: 0.55 kW, 1425 RPM at 50 Hz
Non-submerged; Clutchless compact drive: 8 Nm, 50/60 Hz Non-submerged; Clutchless electronic drive: 0.55 kW at 4200 RPM, 50/60 Hz |
| 81300AJ | Same as 81300A, for jute bags. |
| 81300A1 | Same as 81300A, with guides for filler cord from the top and / or from below for sealing the needle punctures of the left needle. |
| 81300B Needles: 2 Needle distance: 5.0 mm Threads: 4 Stitch range: 6.3-13 mm Standard: 10 mm |
Same as 81300A, but overedge seam width 19 mm = total 24 mm. 5 mm needle distance from needle to needle. For container bags of tubular woven fabric. Sewing capacity up to 16 mm. |
| UN280G132 alternatively: UN280A852L alternatively: UN280A735L |
Non-submerged; Motor: 0.55 kW, 1425 RPM at 50 Hz
Non-submerged; Clutchless compact drive: 8 Nm, 50/60 Hz Non-submerged; Clutchless electronic drive: 0.55 kW at 4200 RPM, 50/60 Hz |
