Heavy Duty Bag Making Machines Styles 80800   .401 SSa-1 (401.401) SSa-2 |
 |
| Styles / Tabling | Description |
| 80800CH Needle: 1 Threads: 2 Stitch range: 6.5-11 mm Standard: 10 mm |
Double locked stitch machine with built-in thread chain cutter and plain feed. For attaching filling and discharching tubes on container bags. Crossing heavy seams is not possible. Sewing capacity up to 17 mm. Max. speed 1800 RPM, stitch type 401. |
| PN282G132 alternatively: UN282G132 |
Pedestal; Motor: 0.55 kW, 1425 RPM at 50 Hz
Non-submerged; Motor: 0.55 kW, 1425 RPM at 50 Hz |
| 80800CDH Needles: 2, staggered Needle distance: 7.2 mm Threads: 4 Stitch range: 7-11 mm Standard: 10 mm |
Two independent rows double locked stitch machine for installation on sewing table or pedestal. Stitch type (401.401). |
| PN282G132 alternatively: UN282G132 |
Pedestal; Motor: 0.55 kW, 1425 RPM at 50 Hz
Non-submerged; Motor: 0.55 kW, 1425 RPM at 50 Hz |
| 80800HAZ3381 Needles: 1 Threads: 2 Stitch range: 6.5-8 mm Standard: 8 mm |
Double locked stitch machine with plain feed. Feeler controlled mechanical operated tape cutter automatically cuts the crepe paper tape and thread chain at the front and the rear of the bag. The projecting length of the tape is approx. 8 inch (20 mm) at both ends. Tape binder for 2 inch (50 mm) (standard) crepe paper tape or 2.5 inch (63 mm) crepe paper tape. Guide for filler cord from the top for sealing the needle punctures. For closing and simultaneously binding paper bag bottoms with a crepe paper tape. Max. speed: 1800 RPM, stitch type 401. |
| UN282G130 |
Non-submerged; Motor: 0.55 kW, 1425 RPM at 50 Hz |
