Double Locked Stitch Machines Styles 56100...B - New B-Series with new needle bearing
|
56100T |  |
..| Styles / Tabling | Description |
| 56100MB Needle: 1 Threads: 2 Stitch range: 3.6-7.3 mm Standard: 7.3 mm |
Double locked stitch machine for seaming light weight cotton and burlap bags. Sewing capacity up to 8 mm. Plain feed, one row feed dog, automatic lubrication, max. speed 6000 RPM, stitch type 401. |
| UH221G130 alternatively: UV226G130 |
Semi submerged; Motor: 0.55 kW, 2850 RPM at 50 Hz
Fully submerged; Motor: 0.55 kW, 2850 RPM at 50 Hz |
| 56100PB | Same as 56100T, but with high needle throw, (1 1/2" = 38 mm) for medium to heavy weight fabrics and without folder. Sewing capacity up to 11 mm. |
| UH221G130 alternatively: UV226G130 |
Semi submerged; Motor: 0.55 kW, 2850 RPM at 50 Hz
Fully submerged; Motor: 0.55 kW, 2850 RPM at 50 Hz |
| 56100TB Needle: 1 Threads: 2 Stitch range: 3.6-7.3 mm Standard: 7.3 mm |
Double locked stitch machine for hemming bag openings and for double turned-in side and bottom seams on light to medium weight bag fabric, specially for woven polypropylene. Adjustable hemmer for hems from 10-25 mm width included, hemmer capacity adjustable 2 and 4 mm . Automatic lubrication, plain feed, sewing capacity up to 8 mm, max. speed 6000 RPM, stitch type 401. |
| UH221G130 alternatively: UV226G130 |
Semi submerged; Motor: 0.55 kW, 2850 RPM at 50 Hz
Fully submerged; Motor: 0.55 kW, 2850 RPM at 50 Hz |
| 56100MZ27B | Same as 56100 M, but with sewing parts of 56100T. |
| UH221G130 alternatively: UV226G130 |
Semi submerged; Motor: 0.55 kW, 2850 RPM at 50 Hz
Fully submerged; Motor: 0.55 kW, 2850 RPM at 50 Hz |
| 56100Z28B Needle: 1 Threads: 2 Stitch range: 3.6-7.3 mm |
Double locked stitch machine for seaming heavy weight multi-wall paper bags. Top and bottom feed. Max. speed: 3800 RPM, stitch type: 401. (Machine can be applied same as former 51100R) |
| UH221G130 alternatively: UV226G130 |
Semi submerged; Motor: 0.55 kW, 2850 RPM at 50 Hz
Fully submerged; Motor: 0.55 kW, 2850 RPM at 50 Hz |
